Raffrescatore evaporativo assiale a risparmio energetico da 30000 m3/h per ventilazione industriale

Informazioni di base

Modello numero:	CY-30TA/DA
Tip	Acqua raffreddata
Acqua di raffreddamento	Acqua industriale
Tipo di sistema	Sistema aperto
Tipi di fan	Ventilatore di frequenza
Livello di rumore	Basso
Campi di applicazione	Elettronico
Certificazione	CE
Condizione	Nuovo
Flusso d'aria	30000m3/ora
Tensione1	Trifase, 220 V, 50 Hz/60 Hz
Tensione2	Trifase, 380 V, 50 Hz/60 Hz
Tipo di ventola	Raffreddatore d'aria assiale
Prestazione	3,0 kW
Rumore	79dB
serbatoio d'acqua	30L-120L
Controllore1	Controllo manuale 1 velocità
Controllore2	Controller inverter di frequenza a 12 velocità
Tipo di presa del vento	Scarico dall'alto verso il basso
Pacchetto di trasporto	Legno o cartone
specifica	CY-30TA/DA
marchio	Yingshi
Origine	Taizhou
Codice HS	84796000
Capacità produttiva	5000/mese

Descrizione del prodotto

Modello:	CY-30TA/DA
Flusso d'aria:	30000 m3/h
voltaggio:	Monofase, 220 V/50 Hz, trifase, 380 V/50 Hz, frequenza variabile
Prestazioni:	3,0KW
Rumore:	≤79dB
Tipo di ventilatore:	Assiale/centrifugo
Serbatoio d'acqua:	30 litri
Regole:	Telecomando 12 velocità, controllo manuale 1 velocità
Tipo di presa del vento:	Scarico dall'alto verso il basso
Misurare:	1,3*1,3*1,18 m(interno)
Peso:	100 chilogrammi
Area utilizzabile:	150-200 mq

If you need more details please contact with me .Cecilia is 24 hours available for you. It's really my honor if I can do any help for you.Axial Evaporative Air Cooler (CY-30TA/DA) we have Top and Down dischargeCY-30TA/DA is the newest model in our factory, the air flow is 30000m3/h, and it has 7 advantages: (1) The special design of the bottom of the air cooler, it makes the machine stronger. (2) The wind barrels using the standalone anechoic wind barrels to reduce the noise. (3) We make a special design on water knockout drum. AS usual many factory uses 8 water knockout drum, it make many stoppages, but we take 4, it can avoid this problem. It's easy to use and maintain. In addition, the water knockout drum is wrapped the wet curtain, it can prevent water droplets splashing(4) We just take one drowned pump, it Reduce the maintenance rate. The importantly, drowned pump can prevent the burn when the water immersion the bottom. (5) The different design of the air cooler covering, solidness is very high; it doesn't need the plastic pipe to support, so it can save the cost. (6) And this new model, can install dust screen, it easy to wash(7) We are the manufacture so we can promise the quality and the beautiful color. We hope you will like this model, Your satisfaction is our goal. We will try our best to create the more powerful and excellent big airflow air coolerPlease comply with below items strictly when using the product. If any happen because of uncorrected usage of the products, the company has no responsibility. 1. The water level should not be over'MAX' scale for any time. In cool mode, the water level should not be under 'MIN' scale. 2. Once the environmental humidity is too high, please use fan function, as cool mode is always with humidity effect. 3. When evaporative cooler is charged with water, make sure that it is without incline or collision when placing or moving to avoid overflow. It is forbidden to turn over the unit in using, prevent accidents. 4. Please do not put anything on the evaporative cooler; Especially covering air outlet is prohibited. Make sure there is no obstacle in 1m distance of the front and back of the unit. 5. When there is no water in tank, the pump won't work in cool mode. 6. The unit has to cut off power supply and plug off during maintenance or clean. 7. Please use a damp cloth (add some detergent) to clean the until. Do not use corrosive solvent and flushing is not allowed. 8. Please plug off the unit immediately, when the unit charged with watet falls down. Only use it after drying it. Otherwise, it may damage the unit...9. Avoid the air inlet and outlet to approaching wall curtain, etc. Otherwise it will choke air, low effect of the unit. 10. Do not knock or vibrate the unit in using, it may cause automatic stop and need restart. 11. Please plug off when the unit is not in use. Note: The control panel can't touch water. Because the unit has high voltage, it has to cut off power supply and plug off when clean. 12. If the power cord is broken in order to avoid danger, it is necessary to changed by professional technicians. 13. Attentions when replacing or changing batteries of remote controller: (1) Replace same specification battery, and notice the polarity. (2) do not free throw waste batteries, prevent environment pollution. (3) Please put out battery if not used for long time.
